| Manufacturer Part Number | S2D300-BP02-37 |
| Manufacturer | ebm-papst Inc. |
| Description | FAN AXIAL |
| Manufacturer Part Number | S2D300BP0237 |
| Series | S2D300 |
| Part Status | Active |
| Voltage - Rated | 230/400VAC |
| Size / Dimension | Round - 360mm Dia |
| Width | 109.0mm |
| Air Flow | 1301.7 CFM (36.45m3/min) |
| Static Pressure | 0.502 in H2O (125.0 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial, 3 Phase |
| Features | Dual Voltage, Thermal Overload Protector (TOP) |
| Noise | - |
| Power (Watts) | 300W |
| RPM | 2750 RPM |
| Termination | 9 Wire Leads with Splice Terminals |
| Ingress Protection | IP44 |
| Operating Temperature | -13 ~ 104～F (-25 ~ 40～C) |
| Approvals | CE, EAC |
| Weight | - |
