| Manufacturer Part Number | W4E315-CS20-71 |
| Manufacturer | ebm-papst Inc. |
| Description | FAN AXIAL |
| Manufacturer Part Number | W4E315CS2071 |
| Series | W4E315 |
| Part Status | Active |
| Voltage - Rated | 230VAC |
| Size / Dimension | Round - 397mm Dia |
| Width | 117.0mm |
| Air Flow | - |
| Static Pressure | 0.341 in H2O (85.0 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Capacitor, Thermal Overload Protector (TOP) |
| Noise | - |
| Power (Watts) | 155W |
| RPM | 1490 RPM |
| Termination | 4 Wire Leads with Splice Terminals |
| Ingress Protection | IP44 |
| Operating Temperature | -13 ~ 158°F (-25 ~ 70°C) |
| Approvals | CE, CSA, UL |
| Weight | - |
