| Manufacturer Part Number | R2E250-RB02-11 |
| Manufacturer | ebm-papst Inc. |
| Description | 250 MM AC CENTRIFUGAL FAN |
| Manufacturer Part Number | R2E250RB0211 |
| Series | RadiCal? R2E250RB |
| Part Status | Active |
| Voltage - Rated | 115VAC |
| Size / Dimension | Round - 255mm Dia |
| Width | 108.0mm |
| Air Flow | 1010.1 CFM (28.28m3/min) |
| Static Pressure | - |
| Bearing Type | Ball |
| Fan Type | Motorized Impellers |
| Features | - |
| Noise | 81.0 dB |
| Power (Watts) | 395W |
| RPM | 3050 RPM |
| Termination | 4 Wire Leads |
| Ingress Protection | IP44 |
| Operating Temperature | -13 ~ 140～F (-25 ~ 60～C) |
| Approvals | UL |
| Weight | 8.3 lbs (3.8kg) |
