| Manufacturer Part Number | R2E140-AE77-05 |
| Manufacturer | ebm-papst Inc. |
| Description | MOTORIZED IMPELLER |
| Manufacturer Part Number | R2E140AE7705 |
| Series | R2E140 |
| Part Status | Active |
| Voltage - Rated | 230VAC |
| Size / Dimension | Round - 140mm Dia |
| Width | 72.00mm |
| Air Flow | - |
| Static Pressure | 0.201 in H2O (50.0 Pa) |
| Bearing Type | Ball |
| Fan Type | Motorized Impellers |
| Features | Capacitor, Thermal Overload Protector (TOP) |
| Noise | - |
| Power (Watts) | 115W |
| RPM | 1500 RPM |
| Termination | 4 Wire Leads with Splice Terminals |
| Ingress Protection | IP44 |
| Operating Temperature | -13 ~ 95°F (-25 ~ 35°C) |
| Approvals | CCC, CE, EAC |
| Weight | 2.4 lbs (1.1kg) |
