| Manufacturer Part Number | A6D630-AN01-01 |
| Manufacturer | ebm-papst Inc. |
| Description | AC AXIAL FAN |
| Manufacturer Part Number | A6D630AN0101 |
| Series | A6D630 |
| Part Status | Active |
| Voltage - Rated | 480VAC |
| Size / Dimension | Round - 630mm Dia |
| Width | 209.5mm |
| Air Flow | 4426.3 CFM (123.94m3/min) |
| Static Pressure | 0.140 in H2O (34.9 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial, 3 Phase |
| Features | Thermal Overload Protector (TOP) |
| Noise | - |
| Power (Watts) | 550W |
| RPM | 1010 RPM |
| Termination | Terminal Block |
| Ingress Protection | IP54 - Dust Protected, Water Resistant |
| Operating Temperature | -40 ~ 131～F (-40 ~ 55～C) |
| Approvals | CCC, CE, EAC, VDE |
| Weight | - |
